M1151(A1) HMMWV
Expanded Capacity Armament Carrier
Specfications
First Produced/Service Dates: | 2004 |
Crew: | 4 |
Armament: | Various weapons/mounts can be fitted, including Remote Weapons Systems (RWS). Weapons include the 5.56mm M249 SAW Machine Gun, 7.62mm M60 MG, 7.62mm M240 MG, M2HB .50 Cal Heavy MG and 40mm Mod 3 MK 19 Automatic Grenade Launcher. Most in Iraq and Afghanistan have specialized armor for the gunners. |
Engine: | 8 Cylinder Turbo-Diesel |
Miscellaneous Info: | The base Expanded Capacity Vehicle is different than other the HMMWV variants as it can be fitted with armor at the factory (e.g. IAP- Integrated Armor Protection) as well as adding supplemental armor packages later. Also, it is based on a vehicle with a heavier chassis, the M1113 Expanded Capacity Vehicle. The M1151A1 (previously called the M1151PI) is the designation of those vehicles with the IAP fitted at the factory. Similar vehicles on the same chassis are the M1152 Cargo Troop/Cargo/Shelter Carrier (2-door/open cargo bed), the M1165 Command-Control/General Purpose Vehicle (four-door/open cargo bed) and the M1167 ITAS/TOW Missile Carrier. |
Data Sheet Available: | M1151A1 HMMWV Specifications Sheet via AM General, LLC |
